Drum Application

20-30kg

20-30kg

180-220kg

Pressure Ratio

3:1

3:1

3:1

Working Pressure (bar)

5-8bar/70-115psi

5-8bar/70-115psi

5-8bar/70-115psi

Max. Fluid Pressure (bar)

24bar

24bar

24bar

Cylinder Dia. (mm)

63mm

63mm

63mm

Air consumption

8bar 110L/min

8bar 110L/min

8bar 110L/min

Max. Free Flow Rate

12L/min

12L/min

12L/min

Suction tube dia.

50mm/1.97”

50mm/1.97”

50mm/1.97”

Suction tube length

440mm/17”

740mm/29”

940mm/37”

Input/output

1/4”/1/2”

1/4”/1/2”

1/4”/1/2”

N.W (kg)

5kg

5.5kg

6kg

Measurement (mm)

155x150x735mm

155x150x1065mm

155x150x1265mm
